Deploy the AWS Gateway API Controller on Amazon EKS

This Deployment Guide provides an end-to-end procedure to install the AWS Gateway API Controller with Amazon Elastic Kubernetes Service.

Amazon EKS is a simple, recommended way of preparing a cluster for running services with AWS Gateway API Controller, however the AWS Gateway API Controller can be used on any Kubernetes cluster on AWS. Check out the Advanced Configurations section below for instructions on how to install and run the controller on self-hosted Kubernetes clusters on AWS.

Prerequisites

Install these tools before proceeding:

  1. AWS CLI,
  2. kubectl - the Kubernetes CLI,
  3. helm - the package manager for Kubernetes,
  4. eksctl- the CLI for Amazon EKS,
  5. jq - CLI to manipulate json files.

Setup

Set your AWS Region and Cluster Name as environment variables. See the Amazon VPC Lattice FAQs for a list of supported regions.

export AWS_REGION=<cluster_region>
export CLUSTER_NAME=<cluster_name>

Create a cluster (optional)

You can easily create a cluster with eksctl, the CLI for Amazon EKS:

eksctl create cluster --name $CLUSTER_NAME --region $AWS_REGION

Allow traffic from Amazon VPC Lattice

You must set up security groups so that they allow all Pods communicating with VPC Lattice to allow traffic from the VPC Lattice managed prefix lists. See Control traffic to resources using security groups for details. Lattice has both an IPv4 and IPv6 prefix lists available.

  1. Configure the EKS nodes' security group to receive traffic from the VPC Lattice network.

    CLUSTER_SG=<your_node_security_group>


    Note

    If you have created the cluster with eksctl create cluster --name $CLUSTER_NAME --region $AWS_REGION command, you can use this command to export the Security Group ID:

    CLUSTER_SG=$(aws eks describe-cluster --name $CLUSTER_NAME --output json| jq -r '.cluster.resourcesVpcConfig.clusterSecurityGroupId')

    1
    2
    3
    4
    PREFIX_LIST_ID=$(aws ec2 describe-managed-prefix-lists --query "PrefixLists[?PrefixListName=="\'com.amazonaws.$AWS_REGION.vpc-lattice\'"].PrefixListId" | jq -r '.[]')
    aws ec2 authorize-security-group-ingress --group-id $CLUSTER_SG --ip-permissions "PrefixListIds=[{PrefixListId=${PREFIX_LIST_ID}}],IpProtocol=-1"
    PREFIX_LIST_ID_IPV6=$(aws ec2 describe-managed-prefix-lists --query "PrefixLists[?PrefixListName=="\'com.amazonaws.$AWS_REGION.ipv6.vpc-lattice\'"].PrefixListId" | jq -r '.[]')
    aws ec2 authorize-security-group-ingress --group-id $CLUSTER_SG --ip-permissions "PrefixListIds=[{PrefixListId=${PREFIX_LIST_ID_IPV6}}],IpProtocol=-1"


Set up IAM permissions

The AWS Gateway API Controller needs to have necessary permissions to operate.

  1. Create a policy (recommended-inline-policy.json) in IAM with the following content that can invoke the Gateway API and copy the policy arn for later use:

    1
    2
    3
    4
    5
    6
    7
    curl https://raw.githubusercontent.com/aws/aws-application-networking-k8s/main/files/controller-installation/recommended-inline-policy.json  -o recommended-inline-policy.json

    aws iam create-policy \
        --policy-name VPCLatticeControllerIAMPolicy \
        --policy-document file://recommended-inline-policy.json

    export VPCLatticeControllerIAMPolicyArn=$(aws iam list-policies --query 'Policies[?PolicyName==`VPCLatticeControllerIAMPolicy`].Arn' --output text)

  2. Create the aws-application-networking-system namespace:

    kubectl apply -f https://raw.githubusercontent.com/aws/aws-application-networking-k8s/main/files/controller-installation/deploy-namesystem.yaml


You can choose from Pod Identities (recommended) and IAM Roles For Service Accounts to set up controller permissions.

Set up the Pod Identities Agent

To use Pod Identities, we need to set up the Agent and to configure the controller's Kubernetes Service Account to assume necessary permissions with EKS Pod Identity.

Read if you are using a custom node role

The node role needs to have permissions for the Pod Identity Agent to do the AssumeRoleForPodIdentity action in the EKS Auth API. Follow the documentation if you are not using the AWS managed policy AmazonEKSWorkerNodePolicy.

  1. Run the following AWS CLI command to create the Pod Identity addon.
    aws eks create-addon --cluster-name $CLUSTER_NAME --addon-name eks-pod-identity-agent --addon-version v1.0.0-eksbuild.1

    kubectl get pods -n kube-system | grep 'eks-pod-identity-agent'


Assign role to Service Account

Create an IAM role and associate it with a Kubernetes service account.

  1. Create a Service Account.

    cat >gateway-api-controller-service-account.yaml <<EOF
    apiVersion: v1
    kind: ServiceAccount
    metadata:
        name: gateway-api-controller
        namespace: aws-application-networking-system
    EOF
    kubectl apply -f gateway-api-controller-service-account.yaml

  2. Create a trust policy file for the IAM role.

    cat >trust-relationship.json <<EOF
    {
        "Version": "2012-10-17",
        "Statement": [
            {
                "Sid": "AllowEksAuthToAssumeRoleForPodIdentity",
                "Effect": "Allow",
                "Principal": {
                    "Service": "pods.eks.amazonaws.com"
                },
                "Action": [
                    "sts:AssumeRole",
                    "sts:TagSession"
                ]
            }
        ]
    }
    EOF

  3. Create the role.

    aws iam create-role --role-name VPCLatticeControllerIAMRole --assume-role-policy-document file://trust-relationship.json --description "IAM Role for AWS Gateway API Controller for VPC Lattice"
    aws iam attach-role-policy --role-name VPCLatticeControllerIAMRole --policy-arn=$VPCLatticeControllerIAMPolicyArn
    export VPCLatticeControllerIAMRoleArn=$(aws iam list-roles --query 'Roles[?RoleName==`VPCLatticeControllerIAMRole`].Arn' --output text)

  4. Create the association

    aws eks create-pod-identity-association --cluster-name $CLUSTER_NAME --role-arn $VPCLatticeControllerIAMRoleArn --namespace aws-application-networking-system --service-account gateway-api-controller


You can use AWS IAM Roles for Service Accounts (IRSA) to assign the Controller necessary permissions via a ServiceAccount.

  1. Create an IAM OIDC provider: See Creating an IAM OIDC provider for your cluster for details.

    eksctl utils associate-iam-oidc-provider --cluster $CLUSTER_NAME --approve --region $AWS_REGION


  2. Create an iamserviceaccount for pod level permission:

    1
    2
    3
    4
    5
    6
    7
    8
    eksctl create iamserviceaccount \
        --cluster=$CLUSTER_NAME \
        --namespace=aws-application-networking-system \
        --name=gateway-api-controller \
        --attach-policy-arn=$VPCLatticeControllerIAMPolicyArn \
        --override-existing-serviceaccounts \
        --region $AWS_REGION \
        --approve


Install the Controller

  1. Run either kubectl or helm to deploy the controller. Check Environment Variables for detailed explanation of each configuration option.

    1
    2
    3
    4
    5
    6
    7
    8
    9
    # login to ECR
    aws ecr-public get-login-password --region us-east-1 | helm registry login --username AWS --password-stdin public.ecr.aws
    # Run helm with either install or upgrade
    helm install gateway-api-controller \
        oci://public.ecr.aws/aws-application-networking-k8s/aws-gateway-controller-chart \
        --version=v1.0.6 \
        --set=serviceAccount.create=false \
        --namespace aws-application-networking-system \
        --set=log.level=info # use "debug" for debug level logs

    kubectl apply -f https://raw.githubusercontent.com/aws/aws-application-networking-k8s/main/files/controller-installation/deploy-v1.0.6.yaml

  2. Create the amazon-vpc-lattice GatewayClass:

    kubectl apply -f https://raw.githubusercontent.com/aws/aws-application-networking-k8s/main/files/controller-installation/gatewayclass.yaml
